Tripp Lite 22.2kW 3-Phase Switched PDU LX Platform Interface 220/230V Outlets (24 C13/6 C19) Touchscreen LCD IEC 309 32A Red 380/400V 0U
Buy from SmartTeck
1.509,59 €
Overview
Tripp Lite 22.2kW 3-Phase Switched PDU LX Platform Interface 220/230V Outlets (24 C13/6 C19) Touchscreen LCD IEC 309 32A Red 380/400V 0U Switched 0U Three-phase Vertical Metal Black
The PDU3XEVSR6G32B 22.2kW 3-Phase Switched Power Distribution Unit provides advanced network control and remote power monitoring with the ability to turn on turn off reboot or lock out power to each outlet. By reducing the frequency of on-site visits these advanced remote capabilities can save you money and reduce downtime.N/AN/AThe 0U PDU features 30 switched 220/230V outlets (24 C13 and 6 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. A 1.8-meter cord with IEC 309 32A Red 380/400V plug connects the PDU to a compatible AC power source generator or protected UPS.N/AN/AThe built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP.N/AN/AA color touchscreen LCD lets you toggle between menus to monitor input current level per phase output current per load bank and per outlet with 1% billing-grade accuracy environmental sensor data and network information. It also generates a unique QR code to allow access to the switchable PDU through a mobile device.N/AN/ADistributes Monitors and Manages Network-Grade AC PowerN/AN/A 22.2kW 380/220V 400/230V switched PDU with 3-phase inputN/A Recommended for network applications requiring individual outlet control load shedding and remote monitoring of critical network componentsN/A IEC 309 32A Red 380/400V plug with 1.8m cord connects to compatible AC power sourceN/A Firmware upgrades support future product enhancementsN/AN/A30 Switched 220/230V Outlets Distribute AC PowerN/AN/A 24 C13 and 6 C19 outlets split into 6 separately breakered load banksN/A Individual outlets can be remotely controlled to power up power down reboot or lock out devicesN/A Plug-lock insert sleeves prevent cables from becoming accidentally disconnectedN/AN/AColor Touchscreen LCDN/AN/A Reports network data including IP address input current level per phase and output current per load bank and per outlet with 1% billing-grade accuracyN/A Generates unique QR code for read-only access to PowerAlert Device Manager via mobile deviceN/A Full access available by logging into PowerAlert Device Manager via browser as user with read/write credentialsN/AN/ABuilt-In LX Platform InterfaceN/AN/A Allows full remote access for power monitoring with email notifications via secure web browser SNMP telnet or SSH N/A Supports 10/100 Mbps auto-sensing for communication with an Ethernet networkN/A Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities N/A No Java requiredN/AN/ABroad Communications CompatibilityN/AN/A Supports IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTPN/A Supports automatic and manual assignment of IP addressN/AN/AEssential Safety FeaturesN/AN/A Tiered access allows administrator and guest to log in via web browserN/A Immediate alert notifications via email or SNMP trapsN/A Supports user-specified alarm notification thresholdsN/A Real-time clock backup maintains day/date even if PDU is unpoweredN/AN/AEasy 0U Installation in EIA-Standard 19 in. RacksN/AN/A Mounts vertically using included toolless buttons or rack-mounting bracketsN/A Included PDUMVROTATEBRKT allows mounting with rear-facing outletsN/AN/A 22.2kW 220/230V 3-phase switched 1.8m 0U PDUN/A 30 individually controllable outlets24 C13 6 C19N/A Built-in LX Platform interface for remote access 24/7N/A IEC 309 32A Red 380/400V PDU input with 1.8m AC power cordN/A Touchscreen LCD with mobile access option via QR codeN/AN/APackage IncludesN/AN/A PDU3XEVSR6G32B 22.2kW 3-Phase Switched PDUN/A Built-in LX Platform interfaceN/A Configuration cableN/A (30) Plug-lock insert sleevesN/A Rack-mounting hardwareN/A PDUMVROTATEBRKT mounting bracket accessoryN/A Owners manual
